On the evolution of the shock waves systems created by the fan blades

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

Fan is one of the noise sources in a modern engine. The fan noise is especially noticeable during takeoff at high angular rotation speeds. In such operating modes, supersonic flow around the tips of the fan blades is realized, which leads to the formation of shock waves that propagate upstream until they exit of the engine channel. As a result, a specific noise is emitted into the front hemisphere, consisting of harmonics that are multiples of the fan rotation frequency. The paper analyzes the described effect based on a simple model of the propagation of a shock waves system. By using energy analysis, it is shown that the system of shock waves with equal amplitude decays faster than a system of shock waves with a spread in amplitude.

Full Text

Restricted Access

About the authors

M. A. Yudin

FAU TsAGI, Research Moscow Complex TsAGI

Author for correspondence.
Email: mikleudin@ya.ru
Russian Federation, st. Radio 17, Moscow, 105005

V. F. Kopiev

FAU TsAGI, Research Moscow Complex TsAGI

Email: mikleudin@ya.ru
Russian Federation, st. Radio 17, Moscow, 105005

S. A. Chernyshev

FAU TsAGI, Research Moscow Complex TsAGI

Email: mikleudin@ya.ru
Russian Federation, st. Radio 17, Moscow, 105005

G. A. Faranosov

FAU TsAGI, Research Moscow Complex TsAGI

Email: mikleudin@ya.ru
Russian Federation, st. Radio 17, Moscow, 105005

M. A. Demyanov

FAU TsAGI, Research Moscow Complex TsAGI

Email: mikleudin@ya.ru
Russian Federation, st. Radio 17, Moscow, 105005

O. P. Bychkov

FAU TsAGI, Research Moscow Complex TsAGI

Email: mikleudin@ya.ru
Russian Federation, st. Radio 17, Moscow, 105005

References

  1. Hawkings D. Multiple tone generation by transonic compressors // J. Sound Vib. 1971. V. 17. № 2. P. 241–250.
  2. Голдстейн М.Е. Аэроакустика. М.: Машиностроение, 1981. 294 с.
  3. Гусев В.А., Руденко О.В. Усиление действия интенсивного фокусированного ультразвука (HIFU) при специальной пространственно-временной модуляции // Акуст. журн. 2013. Т. 59. № 1. С. 52−57.
  4. Руденко О.В., Маков Ю.Н. Звуковой удар: от физики нелинейных волн до акустической экологии // Акуст. журн. 2021. Т. 67. № 1. С. 3−30.
  5. Бахтин В.К., Гурбатов С.Н., Дерябин М.С., Касьянов Д.А. Об особенностях трансформации профиля акустических нелинейных волн, отражаемых от ступенчатой структуры // Акуст. журн. 2023. Т. 69. № 3. С. 295−303.
  6. Ландау Л.Д., Лифшиц Е.М. Теоретическая физика. Т. VI. Гидродинамика. М.: Наука, 1986. 736 с.
  7. Fisher M.J., Tester B.J. and Schwaller P.J.G. Supersonic fan tone noise prediction // AIAA Aeroacoustics conf., Toulouse, 1998.
  8. McAlpine A. and Fisher M.J. On the prediction of "buzz-saw" noise in aero-engine inlet ducts // J. Sound Vib. 2001. V. 248. № 1. P. 123−149.
  9. McAlpine A. and Fisher M.J. On the prediction of "buzz-saw" noise in acoustically lined aero-engine inlet ducts // J. Sound Vib. 2003. V. 265. P. 175−200.
  10. McAlpine A., Fisher M.J., Tester B.J. "Buzz-saw" noise: A comparison of measurement with prediction // J. Sound Vib. 2006. 290. P. 1202−1233.
  11. Stratford B.S. and Newby D.R. A new look at the generation of buzz-saw noise // AIAA Aeroacoustics conf., Atlanta, 1977.
  12. Morfey C.L. and Fisher M.J. Shock-Wave Radiation from a Supersonic Ducted Rotor // The Aeronautical Journal of the Royal Aeronautical Society. 1970. V. 74. P. 579–585.

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. Flow diagram near the tips of blades flown at supersonic speed M = Mₐ²+Mₐ² >1 , where Mₐ and Mτ are the axial and tangential Mach numbers, respectively.

Download (123KB)
Indexing metadata
3. Fig. 2. Regular system of shock waves (λ) is the distance between shocks).

Download (102KB)
Indexing metadata
4. Fig. 3. Schematic representation of the shock wave merging process.

Download (22KB)
Indexing metadata
5. Fig. 4. Comparison of analytical and numerical solutions.

Download (136KB)
Indexing metadata
6. Fig. 5. Evolution of the spectrum of a regular wave system (N is the harmonic number with frequency Nω₀, ω₀ = 2π/T, T is the fan rotation period).

Download (120KB)
Indexing metadata
7. Fig. 6. Evolution of a system with one distinct jump.

Download (177KB)
Indexing metadata
8. Fig. 7. Evolution of the spectrum of the system with one different jump, harmonics at the blade following frequency are highlighted in red.

Download (187KB)
Indexing metadata
9. Fig. 8. Layout of adjacent profiles in the model grid. L is the profile chord. The dotted line shows the profile at the angle of attack α.

Download (47KB)
Indexing metadata
10. Fig. 9. Scheme of the computational domain.

Download (68KB)
Indexing metadata
11. Fig. 10. Results of calculating the pressure field for a regular grid of profiles: (a) — grid 1; (b) — grid 2; (c) — distribution of pressure disturbances along the propagation line for grid 1 (line 1), for grid 2 (line 2) and the amplitude of shock waves for a one-dimensional model (line 3).

Download (288KB)
Indexing metadata
12. Fig. 11. Pressure field obtained as a result of calculating a two-dimensional irregular grid of profiles, and data analysis lines.

Download (113KB)
Indexing metadata
13. Fig. 12. Comparison of numerical simulation data (curve 1) and calculations using a one-dimensional model (curve 2).

Download (407KB)
